Residential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless Steel

  • 1
  • 2

Brand Name : SUNNY

Model Number : Passenger Home Elevator

Certification : CE,ISO9001

Place of Origin : China

MOQ : 1set

Price : $7000~12000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 Set/ Year

Delivery Time : 15~30 days

Packaging Details : container

Name : Passenger Elevator Lift

Load : 250~2000kg

Speed : 0.4~4.0m/s

Warranty : 12 Months

Elevator type : Passenger Elevator Lift

Control Mode : Group Control

Elevator Door : Center Opening Door

Material : 304 Stainless Steel

Model : Passenger Elevator Lift

Type : Passenger Elevator Lift

Use : Mirror Etching Passenger Elevator

Contact Now

Residential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless Steel

Residential Apartment Villa Passenger elevator Classic Model
Machine room less or MR
Load:400/450kg
Speed:0.4/1.0m/s
Stops: 3 or more
OH:2700
Pit:600mm
Shaft:W x D 1550X1700mm
Cabin:W x D x H 925X1075X2300mm
Door opening:700X2100 CO
Shaft Structure by Clinet or by factory
Colors choices

Cabin materials: tempered glass or stainless steel, etc.

Max Travel 0.63-35m, 1.0-60m, 1.5-75m, 1.75-90m, 2.0-100m, 2.5-120m MR/MRL Load(KG) Speed(m/s) Shaft WxD(mm) OH(mm) PIT(mm) Car WxD(mm) OP Door Type
MRL 250 0.4 1450X1250 2700 500 800X900 600X2000 CO
MRL 320 0.4 1550X1500 2700 500 900X1100 700X2000 CO
MRL 400 0.4 1650X1550 2700 500 1000X1200 700X2000 CO
MRL 450 0.63 2000X1700 4100 1700 1100x1100 700x2100 CO
MRL 450 1 2000X1700 4100 1700 1100x1100 700x2100 CO
MRL 450 1.5 2000X1700 4200 1800 1100x1100 700x2100 CO
MRL 630 1 1790X1720 3600 1200 1400X1100 900X2100 CO
MRL 630 1.5 1790X1720 4200 1800 1400X1100 900X2100 CO
MRL 630 1.75 1790X1720 4200 1800 1400X1100 900X2100 CO
MRL 800 1 1750X1950 4200 1500 1350X1450 800X2100 CO
MRL 800 1.5 1750X1950 4200 1800 1350X1450 800X2100 CO
MRL 800 1.75 1750X1950 4200 1800 1350X1450 800X2100 CO
MRL 1000 1 2050X2000 4350 1500 1600X1400 900X2100 CO
MRL 1000 1.5 2050X2000 4500 1600 1600X1400 900X2100 CO
MRL 1000 1.75 2050X2000 4550 1600 1600X1400 900X2100 CO
MRL 1150 1 2700X1800 4400 1500 1800X1400 1100X2100 CO
MRL 1150 1.5 2700X1800 4400 1500 1800X1400 1100X2100 CO
MRL 1150 1.75 2700X1800 4500 1600 1800X1400 1100X2100 CO
MRL 1250 1 2900X2000 4100 1700 1900X1500 1100X2100 CO
MRL 1250 1.5 2900X2000 4200 1800 1900X1500 1100X2100 CO
MRL 1250 1.75 2900X2000 4200 1800 1900X1500 1100X2100 CO
MRL 1350 1 2500X2150 4350 1550 2000X1500 1100X2100 CO
MRL 1350 1.5 2500X2150 4500 1600 2000X1500 1100X2100 CO
MRL 1350 1.75 2500X2150 4500 1600 2000X1500 1100X2100 CO
MRL 1600 1 2600X2300 4350 1500 1900X1700 1100X2100 CO
MRL 1600 1.5 2600X2300 4400 1500 1900X1700 1100X2100 CO
MRL 1600 1.75 2600X2300 4500 1600 1900X1700 1100X2100 CO
MR H≥2000(2000-2800) MR/MRL Load(KG) Speed(m/s) Shaft WxD(mm) OH(mm) PIT(mm) Car WxD(mm) OP Door Type
MR 450 0.63 1600X1700 4200 1400 1100X1100 700X2100 CO
MR 450 1 1600X1700 4200 1500 1100X1100 700X2100 CO
MR 450 1.5 1600X1700 4400 1600 1100X1100 700X2100 CO
MR 630 0.63 1900X1700 4200 1400 1400X1100 800X2100 CO
MR 630 1 1900X1700 4200 1400 1400X1100 800X2100 CO
MR 630 1.5 1900X1700 4600 1500 1400X1100 800X2100 CO
MR 630 1.75 1900X1700 4600 1600 1400X1100 800X2100 CO
MR 800 1 2000X2000 4200 1500 1400X1350 800X2100 CO
MR 800 1.5 2000X2000 4200 1500 1400X1350 800X2100 CO
MR 800 1.75 2000X2000 4600 1700 1400X1350 800X2100 CO
MR 800 2 2000X2000 4800 1900 1400X1350 800X2100 CO
MR 800 2.5 2000X2000 5100 2100 1400X1350 800X2100 CO
MR 1000 1 2200X2200 4200 1500 1600X1500 900X2100 CO
MR 1000 1.5 2200X2200 4200 1500 1600X1500 900X2100 CO
MR 1000 1.75 2200X2200 4600 1700 1600X1500 900X2100 CO
MR 1000 2 2200X2200 4800 1900 1600X1500 900X2100 CO
MR 1000 2.5 2200X2200 5100 2100 1600X1500 900X2100 CO
MR 1250 1 2400X2200 4500 1400 1900X1500 1100X2100 CO
MR 1250 1.5 2400X2200 4600 1500 1900X1500 1100X2100 CO
MR 1250 1.75 2400X2200 4700 1600 1900X1500 1100X2100 CO
MR 1250 2 2400X2200 4900 1700 1900X1500 1100X2100 CO
MR 1250 2.5 2400X2200 5100 1900 1900X1500 1100X2100 CO
MR 1350 1 2400X2300 4400 1500 1900X1600 1100X2100 CO
MR 1350 1.5 2400X2300 4500 1600 1900X1600 1100X2100 CO
MR 1350 1.75 2400X2300 4600 1700 1900X1600 1100X2100 CO
MR 1350 2 2400X2300 4700 1800 1900X1600 1100X2100 CO
MR 1350 2.5 2400X2300 4900 2000 1900X1600 1100X2100 CO
MR 1350 4 2400X2300 5900 3800 1900X1600 1100X2100 CO
MR 1600 1 2500X2450 4400 1350 2000X1700 1200X2100 CO
MR 1600 1.5 2500X2450 4450 1350 2000X1700 1200X2100 CO
MR 1600 1.75 2500X2450 4500 1400 2000X1700 1200X2100 CO
MR 1600 2 2500X2450 4700 1800 2000X1700 1200X2100 CO
MR 1600 2.5 2500X2450 4900 2000 2000X1700 1200X2100 CO
MR 1600 4 2500X2450 5900 3800 2000X1700 1200X2100 CO
MR 2000 1 2850X2850 4200 1500 1700X2300 1100X2100 CO
MR 2000 1.5 2850X2850 4600 1600 1700X2300 1100X2100 CO
MR 2000 1.75 2850X2850 4600 1600 1700X2300 1100X2100 CO
The parameters are subject to the engineer's final design

Residential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless SteelResidential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless SteelResidential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless SteelResidential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless Steel

Residential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless Steel

Residential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless Steel

Residential Apartment Machine Room Less Or MR Passenger Lift With Tempered Glass Or Stainless Steel

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
